The Pipe Fitters Field Book

Special Price $32.62 Regular Price $36.25

In stock

Product Code

9780973074208

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

The Pipe Fitters Field Book

Includes information on pipe flanges, butt and socket weld fittings, diameters, circumferences and nominal wall thicknesses of pipe, gaskets, rigging hand signals, the safe working load of wire and fiber ropes, slings, common building materials, trade related formulas and other trade reference material.

Quick access information to help you perform your job safely and efficiently.

30+ full color pages with detailed tables, diagrams and formulas.

Pocket-sized for convenience and laminated for durability.

BOOK INCLUDES:

Length through hub for weld neck and slip-on flanges.
Dimensions of butt weld fittings, socket weld fittings and flanges.
Diameters and circumferences and nominal wall thicknesses of pipe.
Odd angles for long radius 90 degree elbows.
Dissecting a circle and blind flange lay out.
Detailed flange specifications for flange series 150-2500
Drill and tap sizes for bolts and pipe.
Weights for common building materials.
Trade related formulas.
Head pressures of water and temperature conversions.
Layout for equal and unequal diameter branch lines at any angle.
Shackles, inside width at the pin and the safe working load.
Snatch block and sling leg load multiplication factors.
The safe working load for wire rope, and nylon and wire rope slings.
Conversion multipliers and trade related formulas.
Explosive limits and specific gravity of different gasses.
Pipe and water weights.
Weights for plate steel.
Weights for flanged gate valves, weld fittings, blind flanges and weld neck flanges.
