Using Multisim 6.1 Troubleshooting DC/AC Circuits by John Reeder

Customer Service

This unique workbook teaches how to troubleshoot circuits with the help MultiSIM™ 6.1. Working on the computer, you will learn to make measurements, replace components, and test results just as you would in a lab. Circuits contain built-in faults to give you troubleshooting practice. This exciting approach quickly builds the skill and confidence needed to do live circuit troubleshooting.

Features:

• Each chapter includes References, Objectives, Introduction, Activities, and Troubleshooting Problems. Introductions provide the background theory. Activities bridge the gap between theory and practice. Troubleshooting Problems test knowledge learned by asking you to determine the problem behind a faulty circuit.
• Step-by-step procedures guide in making test measurements, gathering data, and making observations and conclusions.
• Use of screen captures lead you through the software and allows you to know exactly what to expect.
• Numerous Activities within a chapter allow flexibility to pick and choose and focus on selected areas.
• An accompanying CD includes all the circuit files created in MultiSIM™6.1 needed to work through the Activities.

Published/Edition: Cengage/2000 ISBN/Book No.:0766811336
