Full Length Roof Framer
Full-Length Roof Framer
The Full-Length Roof Framer is a practical reference guide designed for roof layout, rafter cutting, and framing calculations. It contains a comprehensive series of tables that provide the full length of rafters for any given span across 48 different roof pitches, making it a useful tool for carpenters, framers, roofers, builders, and students learning roof framing.
This guide includes detailed information for determining the proper cuts and bevels for a wide range of roof framing members, including common rafters, hip rafters, valley rafters, jack rafters, and purlin rafters. It also provides cuts and bevels for gable and cornice mouldings, helping users achieve accurate layout and fitting for both structural and finish framing work.
Each of the 48 roof pitches is accompanied by illustrations to help clarify the proper angles, cuts, and framing relationships. These visual references make the tables easier to understand and apply in the field.
This revised edition also includes metric framing tables for the ten most common base-12 roof slopes, offering added convenience for users working with metric measurements or modern framing requirements. Overall, the book serves as a dependable shop and jobsite reference for calculating rafter lengths, identifying roof pitch relationships, and making accurate roof framing cuts.
9781622701513
Publication date: 6/28/1995 - Reprint 6/16/2017
Edition description: Reprint
Pages: 115
Product dimensions: 4.26 (w) x 6.86 (h) x 0.48 (d)
| Price | $24.95 |
|---|---|
